Specifications |
|||
|---|---|---|---|
| Manufacturer | Nissei | ||
| Year | 2010 | ||
| Model | TNX50R5V | ||
| Clamping Force | 53 US Ton | ||
| Screw diameter: 26mm Shot size: 1.66 oz. Screw stroke: 3.6" Clamp stroke: 9.84" Min mold thickness: 9.4" / 240mm
Daylight opening: 19.3" / 490mm"Platen size: 21.7" x 15.7" Ejector stroke: 1.97" Rotary table Machine dimensions: 8.7' x 5.2' x 9.6' Weight: 7,600 lbs. |
|||
